Category 13: functional printing
Hospital bed controller set consisting of two membrane switches, with one switch mounted around a tight radius side panel. We ask the judges to focus on the the technical difficulty of both laminating and embossing around such a tight radius when domes can easily be dislodged and self actuate. Consistency of emboss height was critical. The second membrane switch has very fine conductive traces overprinted in perfect register with graphite. The LED windows are printed with a opaque layer in perfect register to prevent light bleed (not visible when not in operation). The halftone printing on the overlay is perfect and consistent. For the client this product solves many issues. It makes the most efficient use of space possible on the multi-control bed. It is multi-function and works for the user whether the bed is in the up or down position
This Dial is printed on top surface with 9 impressions as well as sub - surface with 10 impressions. Flourescent inks are used in sub-surface to give the same illumination for day as well as night . A great care was taken while printing on both the surfaces as the back lit function of the dial had to be maintained , along with the finishing procedures of blanking and punching .
Flexible Membrane Keypad with inbuilt Leds. Used frame 70 number, used polyster sheet for overlay, used adhesive 3m, part number is 467-3m, Flexible Keyboards that is designed using the latest technology. The offered keyboard is manufactured at our well equipped manufacturing unit utilizing utmost-grade components and contemporary technology in compliance with the set industrial norms.
This Dial is printed on top surface with 5 impressions as well as sub - surface with 3 impressions. It is a High precision formed 3D Dial . A great care was taken while printing and forming . The finishing procedures is blanking
Pool chlorine Pump controller overlay. Fine screen printed text with butt registration colour to colour. Reverse printed on polyester. A demanding application for inks and adhesive. Focus on the positive text and the difficulty of the reversed TM in the logo and the transparent windows with a blocker layer to prevent light bleed.
